Parts List
Below is an index of the components used to construct the submersible robot. The heading of each section serves a link to a word file containing a picture and detailed information about each part.
No. Part Description Quantity Weight 1) 3/8” Flare to ¼” Male Pipe Elbow 1 52.25g 2) 3/8” Flare to Flare Elbow 1 67.5g 3) ¼” Pipe Coupling 1 18.65g 4) ¼” Flare Fitting 18 12.1g 5) ¼” Flare to MIP Fitting 1 17.3g 6) 3/8” Flare Fitting 2 15.9g 7) 1/8” to ¼” Flare Fitting 10 12.7g 8) ½” to 3/8” Flare Fitting 1 35.1g 9) ¼” 3-Way T Fitting 2 33.3g 10) One-Way check Valve 1 79.25g 11) 12oz CO2 Canister with On/Off Valve 1 790.0g
12) Direct Acting Solenoid Valve 4 454.35g 13) Coin Cell Battery 8 6.55g 14) Photo Voltaic Cell 1 25g 15) Micro Controller 1 90.7g
16) 4” Diameter Clear, Threaded PVC Pipe 2 665.95g 17) 4” PVC Coupler 1 584.85g 18) PVC Sheet, round 1 180.45g 19) 4” Threaded PVC END Cap 4 407.1g 20) 3” PVC End Cap 1 211.5g 21) 3” PVC End Cap and Coupler 1 547.0g 22) 3” PVC Pipe 1 299.05g 23) 4” PVC Inner Coupler 2 66.4g
24) 1” PVC Barb to Threaded Fitting 6 26.5g 25) 2” PVC Barb to Threaded Fitting 2 82.2g 26) 1” Inner Diameter Hose 3 N/A 27) 2” Inner Diameter Rubber Hose 1 N/A |
|
|
